THE BMW X4: ENGINES & TECHNICAL DATA

THE X4THE BMW X4: ENGINES & TECHNICAL DATA

TECHNICAL DATA OF THE BMW X4.

Select model

Weight

Unladen weight EU in kg 1,875
Max. permissible weight in kg 2,420
Permitted load in kg 620
Permitted axle load front/rear in kg 1,160/1,400
Luggage capacity min. (seats up or roof down) in l 525
Luggage capacity max. (seats down or roof up) in l 1,430
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg 2,400-2,000

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 135 (184)/5,000-6,500
Engine torque (Nm) at 1/min 300/1,350-4,000
Compression ratio : 1 11.0

Performance

Top speed in km/h 215
Acceleration 0–100 km/h in s 8.4-8.3

Fuel consumption

Urban in l/100 km 8.8
Extra-urban in l/100 km 7.0
Combined in l/100 km 7.7
CO2 combined emissions in g/km 175
Tank capacity, approx. in l 65

Wheels

Tyre dimensions front 225/60 R18 104 W XL
Tyre dimensions rear 225/60 R18 104 W XL
Wheel dimensions and material front 7 J x 18 inches, light-alloy
Wheel dimensions and material rear 7 J x 18 inches, light-alloy

Weight

Unladen weight EU in kg 1,890
Max. permissible weight in kg 2,450
Permitted load in kg 635
Permitted axle load front/rear in kg 1,160/1,400
Luggage capacity min. (seats up or roof down) in l 525
Luggage capacity max. (seats down or roof up) in l 1,430
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg 2,400-2,000

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 185 (252)/5,200-6,500
Engine torque (Nm) at 1/min 350/1,450-4,800
Compression ratio : 1 10.2

Performance

Top speed in km/h 242-235
Acceleration 0–100 km/h in s 8.3-6.4

Fuel consumption

Urban in l/100 km 9.0
Extra-urban in l/100 km 7.2
Combined in l/100 km 7.9
CO2 combined emissions in g/km 180
Tank capacity, approx. in l 65

Wheels

Tyre dimensions front 225/60 R18 104 W XL
Tyre dimensions rear 225/60 R18 104 W XL
Wheel dimensions and material front 7 J x 18 inches, light-alloy
Wheel dimensions and material rear 7 J x 18 inches, light-alloy

Weight

Unladen weight EU in kg 1,995
Max. permissible weight in kg 2,500
Permitted load in kg 580
Permitted axle load front/rear in kg 1,220/1,425
Luggage capacity min. (seats up or roof down) in l 525
Luggage capacity max. (seats down or roof up) in l 1,430
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg 2,400-2,000

Engine

Cylinders/valves 6/4
Capacity in ccm 2.998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 285 (387)/5,800-6,500
Engine torque (Nm) at 1/min 500/1,900-5,000
Compression ratio : 1 10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4,9-4,5

Fuel consumption

Urban in l/100 km 11.2
Extra-urban in l/100 km 7.6
Combined in l/100 km 8.9
CO2 combined emissions in g/km 204
Tank capacity, approx. in l 65

Wheels

Tyre dimensions front 245/45 R20 103 W XL
Tyre dimensions rear 275/40 R20 106 W XL
Wheel dimensions and material front 8 J x 20 inches, light-alloy
Wheel dimensions and material rear 9.5 J x 20 inches, light-alloy

Weight

Unladen weight EU in kg 1,915-1,845
Max. permissible weight in kg 2,450-2,440
Permitted load in kg 670-610
Permitted axle load front/rear in kg 1,200/1,420-1,400
Luggage capacity min. (seats up or roof down) in l 525
Luggage capacity max. (seats down or roof up) in l 1,430
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg 2,400-2,000

Engine

Cylinders/valves 4/4
Capacity in ccm 1,995
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 140 (190)/4,000
Engine torque (Nm) at 1/min 400/1,750-2,500
Compression ratio : 1 16.5

Performance

Top speed in km/h 213-205
Acceleration 0–100 km/h in s 9.0-7.9

Fuel consumption

Urban in l/100 km 6.4-6.3
Extra-urban in l/100 km 5.7-5.1
Combined in l/100 km 5.9-5.6
CO2 combined emissions in g/km 156-147
Tank capacity, approx. in l 68

Wheels

Tyre dimensions front 225/60 R18 104 W XL
Tyre dimensions rear 225/60 R18 104 W XL
Wheel dimensions and material front 7 J x 18 inches, light-alloy
Wheel dimensions and material rear 7 J x 18 inches, light-alloy

Weight

Unladen weight EU in kg 2,010-1,945
Max. permissible weight in kg 2,530-2,500
Permitted load in kg 630-595
Permitted axle load front/rear in kg 1,220-1,215/1,435-1,415
Luggage capacity min. (seats up or roof down) in l 525
Luggage capacity max. (seats down or roof up) in l 1,430
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg 2,400-2,000

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 210 (286)/4,000
Engine torque (Nm) at 1/min 650/1,500-2,500
Compression ratio : 1 16.5

Performance

Top speed in km/h 245-235
Acceleration 0–100 km/h in s 6.0-5.7

Fuel consumption

Urban in l/100 km 7.4-7.3
Extra-urban in l/100 km 6.1-5.9
Combined in l/100 km 6.6-6.4
CO2 combined emissions in g/km 173-169
Tank capacity, approx. in l 68

Wheels

Tyre dimensions front 225/60 R18 104 W XL
Tyre dimensions rear 225/60 R18 104 W XL
Wheel dimensions and material front 7 J x 18 inches, light-alloy
Wheel dimensions and material rear 7 J x 18 inches, light-alloy

Weight

Unladen weight EU in kg 2,095-2,020
Max. permissible weight in kg 2,560-2,525
Permitted load in kg 580-540
Permitted axle load front/rear in kg 1,230-1,220/1,430
Luggage capacity min. (seats up or roof down) in l 525
Luggage capacity max. (seats down or roof up) in l 1,430
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg 2,400-2,000

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 240 (326)/4,400
Engine torque (Nm) at 1/min 680/1,750-2,750
Compression ratio : 1 16.5

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.9

Fuel consumption

Urban in l/100 km 7.5-7.4
Extra-urban in l/100 km 6.3-6.2
Combined in l/100 km 6.7-6.6
CO2 combined emissions in g/km 177-174
Tank capacity, approx. in l 68

Wheels

Tyre dimensions front 245/45 R20 103 W XL
Tyre dimensions rear 275/40 R20 106 W XL
Wheel dimensions and material front 8 J x 20 inches, light-alloy
Wheel dimensions and material rear 9.5 J x 20 inches, light-alloy

Fuel consumption and CO2 emissions of the BMW X4.

BMW X4 xDrive30i:
Fuel consumption in l/100 km (combined): 8.5–7.9
CO2 emissions in g/km (combined): 193–171

BMW X4 M40i:
Fuel consumption in l/100 km (combined): 9.5–8.7
CO2 emissions in g/km (combined): 216–198


Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp

Read more
​

Fuel consumption and CO2 emissions of the BMW X4.

  • BMW X4 xDrive30i:
    Fuel consumption in l/100 km (combined): 7.9
    CO2 emissions in g/km (combined): 180

    BMW X4 M40i:
    Fuel consumption in l/100 km (combined): 8.9
    CO2 emissions in g/km (combined): 204

    The values of fuel consumptions, CO2 emissions and energy consumptions shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

    The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the European Regulation in its current version applicable. The values shown are based on the fuel consumption, CO2 values and energy consumptions according to the NEDC cycle for the classification.

    For further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the „handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars“, which is available at all selling points and at https://www.dat.de/angebote/verlagsprodukte/leitfaden-kraftstoffverbrauch.html.
