BMW 5 SERIES SEDAN: ENGINES & TECHNICAL DATA

THE 5BMW 5 SERIES SEDAN: ENGINES & TECHNICAL DATA

The key facts and figures for the BMW 5 Series Sedan at a glance: engines, consumption, CO2 emissions and dimensions. Check out all the performance data such as displacement, horsepower, torque and acceleration – and find out which engine best meets your needs.

Read more

TECHNICAL DATA.

Weight
Unladen weight EU in kg
1,655
Max. permissible weight in kg
2,250
Permitted load in kg
670
Permitted axle load front/rear in kg
1,265/1,045
Luggage capacity min. (seats up or roof down) in l
530
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
4/4
Capacity in ccm
1.597
Stroke/bore in mm
75.6/82.0
Engine power in kW (hp) at 1/min
135 (184)/5,000-6,500
Engine torque (Nm) at 1/min
290/1,350-4,250
Compression ratio : 1
11.0
Performance
Top speed in km/h
235
Acceleration 0–100 km/h in s
7.9-7.8
Electrical engine top speed in km/h
-
Fuel consumption
Urban in l/100 km
8.6-8.5
Extra-urban in l/100 km
6.2-5.8
Combined in l/100 km
7.1-6.8
CO2 combined emissions in g/km
162-156
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
68
Wheels
Tyre dimensions front
225/55 R17 101 Y XL
Tyre dimensions rear
225/55 R17 101 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,700
Max. permissible weight in kg
2,305
Permitted load in kg
680
Permitted axle load front/rear in kg
1,300/1,090
Luggage capacity min. (seats up or roof down) in l
530
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
183-185 (249-252)/5,200-6,500
Engine torque (Nm) at 1/min
350/1,450-4,800
Compression ratio : 1
10.2
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
6.4-6.1
Electrical engine top speed in km/h
-
Fuel consumption
Urban in l/100 km
8.1
Extra-urban in l/100 km
5.9
Combined in l/100 km
6.7
CO2 combined emissions in g/km
154
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
68
Wheels
Tyre dimensions front
225/55 R17 101 Y XL
Tyre dimensions rear
225/55 R17 101 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,755
Max. permissible weight in kg
2,360
Permitted load in kg
680
Permitted axle load front/rear in kg
1,140/1,310
Luggage capacity min. (seats up or roof down) in l
530
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
183-185 (249-252)/5,200-6,500
Engine torque (Nm) at 1/min
350/1,450-4,800
Compression ratio : 1
10.2
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
6.3-6.0
Electrical engine top speed in km/h
-
Fuel consumption
Urban in l/100 km
8.9
Extra-urban in l/100 km
6.3
Combined in l/100 km
7.3
CO2 combined emissions in g/km
166
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
68
Wheels
Tyre dimensions front
225/55 R17 101 Y XL
Tyre dimensions rear
225/55 R17 101 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,760
Max. permissible weight in kg
2,395
Permitted load in kg
710
Permitted axle load front/rear in kg
1,155/1,320
Luggage capacity min. (seats up or roof down) in l
530
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
6/4
Capacity in ccm
2,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
245-250 (333-340)/5,500-6,250 - 5,500-6,500
Engine torque (Nm) at 1/min
450/1,600-4,800 - 1,500-5,200
Compression ratio : 1
11.0
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
5.2-5.1
Electrical engine top speed in km/h
-
Fuel consumption
Urban in l/100 km
10.1
Extra-urban in l/100 km
6.3
Combined in l/100 km
7.7
CO2 combined emissions in g/km
176
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
68
Wheels
Tyre dimensions front
225/55 R17 101 Y XL
Tyre dimensions rear
225/55 R17 101 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,820
Max. permissible weight in kg
2,455
Permitted load in kg
710
Permitted axle load front/rear in kg
1,200-1,330
Luggage capacity min. (seats up or roof down) in l
530
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
6/4
Capacity in ccm
2,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
245-250 (333-340)/5,500-6,250 - 5,500-6,500
Engine torque (Nm) at 1/min
450/1,600-4,800 - 1,500-5,200
Compression ratio : 1
11.0
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
4.9-4.7
Electrical engine top speed in km/h
-
Fuel consumption
Urban in l/100 km
10.2
Extra-urban in l/100 km
6.3
Combined in l/100 km
7.9
CO2 combined emissions in g/km
182
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
68
Wheels
Tyre dimensions front
225/55 R17 101 Y XL
Tyre dimensions rear
225/55 R17 101 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,990
Max. permissible weight in kg
2,560
Permitted load in kg
645
Permitted axle load front/rear in kg
1,260/1,365
Luggage capacity min. (seats up or roof down) in l
530
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
8/4
Capacity in ccm
4,395
Stroke/bore in mm
88.3/89.0
Engine power in kW (hp) at 1/min
390 (530)/5,500-6,000
Engine torque (Nm) at 1/min
750/1,800-4,600
Compression ratio : 1
10.5
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
3.8
Electrical engine top speed in km/h
-
Fuel consumption
Urban in l/100 km
14.9
Extra-urban in l/100 km
8.3
Combined in l/100 km
10.7
CO2 combined emissions in g/km
246
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
68
Wheels
Tyre dimensions front
245/40 R19 98 Y XL
Tyre dimensions rear
275/35 R19 100 Y XL
Wheel dimensions and material front
8 J x 19 inches, light-alloy
Wheel dimensions and material rear
9 J x 19 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,745
Max. permissible weight in kg
2,340
Permitted load in kg
670
Permitted axle load front/rear in kg
1,090/1,310
Luggage capacity min. (seats up or roof down) in l
530
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
4/4
Capacity in ccm
1,995
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
110 (150)/4,000
Engine torque (Nm) at 1/min
350/1,750-2,500
Compression ratio : 1
16.5
Performance
Top speed in km/h
220
Acceleration 0–100 km/h in s
8.8
Electrical engine top speed in km/h
-
Fuel consumption
Urban in l/100 km
5.8
Extra-urban in l/100 km
4.8
Combined in l/100 km
5.2
CO2 combined emissions in g/km
136
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
66
Wheels
Tyre dimensions front
225/55 R17 101 Y XL
Tyre dimensions rear
225/55 R17 101 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,750
Max. permissible weight in kg
2,345
Permitted load in kg
670
Permitted axle load front/rear in kg
1,100/1,320
Luggage capacity min. (seats up or roof down) in l
530
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
4/4
Capacity in ccm
1,995
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
140 (190)/4,000
Engine torque (Nm) at 1/min
400/1,750-2,500
Compression ratio : 1
16.5
Performance
Top speed in km/h
235
Acceleration 0–100 km/h in s
7.5-7.3
Electrical engine top speed in km/h
-
Fuel consumption
Urban in l/100 km
6.0-5.8
Extra-urban in l/100 km
4.9-4.7
Combined in l/100 km
5.2
CO2 combined emissions in g/km
137
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
66
Wheels
Tyre dimensions front
225/55 R17 101 Y XL
Tyre dimensions rear
225/55 R17 101 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,810
Max. permissible weight in kg
2,405
Permitted load in kg
670
Permitted axle load front/rear in kg
1,150/1,330
Luggage capacity min. (seats up or roof down) in l
530
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
4/4
Capacity in ccm
1,995
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
140 (190)/4,000
Engine torque (Nm) at 1/min
400/1,750-2,500
Compression ratio : 1
16.5
Performance
Top speed in km/h
232
Acceleration 0–100 km/h in s
7.6-7.3
Electrical engine top speed in km/h
-
Fuel consumption
Urban in l/100 km
6.2-6.1
Extra-urban in l/100 km
5.1-4.8
Combined in l/100 km
5.5-5.3
CO2 combined emissions in g/km
144-139
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
66
Wheels
Tyre dimensions front
225/55 R17 101 Y XL
Tyre dimensions rear
225/55 R17 101 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,835
Max. permissible weight in kg
2,440
Permitted load in kg
680
Permitted axle load front/rear in kg
1,200/1,350
Luggage capacity min. (seats up or roof down) in l
530
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
6/4
Capacity in ccm
2,993
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
210 (286)/4,000
Engine torque (Nm) at 1/min
650/1,500-2,500
Compression ratio : 1
16.5
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
5.6
Electrical engine top speed in km/h
-
Fuel consumption
Urban in l/100 km
6.1-5.9
Extra-urban in l/100 km
4.2-4.0
Combined in l/100 km
4.9-4.7
CO2 combined emissions in g/km
128-123
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
66
Wheels
Tyre dimensions front
225/55 R17 101 Y XL
Tyre dimensions rear
225/55 R17 101 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,895
Max. permissible weight in kg
2,505
Permitted load in kg
685
Permitted axle load front/rear in kg
1,250/1,360
Luggage capacity min. (seats up or roof down) in l
530
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
6/4
Capacity in ccm
2,993
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
183-195 (248-265)/4,000
Engine torque (Nm) at 1/min
620/2,000-2,500
Compression ratio : 1
16.5
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
5.5-5.4
Electrical engine top speed in km/h
-
Fuel consumption
Urban in l/100 km
7.3
Extra-urban in l/100 km
5.1
Combined in l/100 km
5.9
CO2 combined emissions in g/km
155
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
66
Wheels
Tyre dimensions front
225/55 R17 101 Y XL
Tyre dimensions rear
225/55 R17 101 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,925
Max. permissible weight in kg
2,525
Permitted load in kg
675
Permitted axle load front/rear in kg
1,270/1,360
Luggage capacity min. (seats up or roof down) in l
530
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
2,000
Trailer load 12% (braked) in kg
2,000
Engine
Cylinders/valves
6/4
Capacity in ccm
2,993
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
250 (340)/4,400
Engine torque (Nm) at 1/min
700/1,750-2,250
Compression ratio : 1
16.5
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
4.6
Electrical engine top speed in km/h
-
Fuel consumption
Urban in l/100 km
6.8-6.6
Extra-urban in l/100 km
4.6-4.5
Combined in l/100 km
5.4-5.3
CO2 combined emissions in g/km
142-138
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
66
Wheels
Tyre dimensions front
225/55 R17 101 Y XL
Tyre dimensions rear
225/55 R17 101 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium-ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (PS) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (PS)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,910
Max. permissible weight in kg
2,505
Permitted load in kg
670
Permitted axle load front/rear in kg
1,120/1,450
Luggage capacity min. (seats up or roof down) in l
410
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,700
Trailer load 12% (braked) in kg
1,700
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
135 (184)/5,000-6,500
Engine torque (Nm) at 1/min
300/1,350-4,000
Compression ratio : 1
11.0
Performance
Top speed in km/h
235
Acceleration 0–100 km/h in s
5.9
Electrical engine top speed in km/h
140
Fuel consumption
Urban in l/100 km
-
Extra-urban in l/100 km
-
Combined in l/100 km
2.3
CO2 combined emissions in g/km
53
Electricity consumption, combined in kWh/100km
17.6
Tank capacity, approx. in l
46
Wheels
Tyre dimensions front
225/55 R17 101 Y XL
Tyre dimensions rear
225/55 R17 101 Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Range and charging
Electric range in km
45
Growth capacity of lithium-ion battery in kWh
12.0
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
3.4
Electric engine
Electric engine power kW (PS) at 1/min
83 (113)/3,170
Electric Engine torque (Nm) at 1/min
250/0-3,170
Combined system power
Combined power kW (PS)
185 (252)
Combined torque Nm
420
Weight
Unladen weight EU in kg
1,970
Max. permissible weight in kg
2,560
Permitted load in kg
665
Permitted axle load front/rear in kg
1,170/1,455
Luggage capacity min. (seats up or roof down) in l
410
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,700
Trailer load 12% (braked) in kg
1,700
<
