BMW 3 SERIES SEDAN M AUTOMOBILES: ENGINES & TECHNICAL DATA

THE M3BMW 3 SERIES SEDAN M AUTOMOBILES: ENGINES & TECHNICAL DATA

BMW M3 Competition Sedan, BMW M3 Sedan, BMW M340i xDrive – engines, facts and dimensions.

The key facts and figures for the BMW M3 Competition Sedan, BMW M3 Sedan, BMW M340i xDrive at a glance: find out all about engines, consumption, CO2 emissions and dimensions of the various BMW M3 models. Compare impressive performance data such as displacement, hp, Nm and acceleration – and discover which of these four exceptional sports sedans suits you best.

ENGINES AND TECHNICAL DATA OF THE BMW 3 SERIES SEDAN M AUTOMOBILES.

Select model

Weight

Unladen weight EU in kg 1,805
Max. permissible weight in kg 2,210
Permitted load in kg 480
Permitted axle load front/rear in kg 1,080/1,180
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg -
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg -

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 375 (510)/6,250
Engine torque (Nm) at 1/min 650/2,750-5,500
Compression ratio : 1 9.3

Performance

Top speed in km/h 250 (290)
Acceleration 0–100 km/h in s 3.9

Fuel consumption

Urban in l/100 km 13.2
Extra-urban in l/100 km 7.5
Combined in l/100 km 9.6
CO2 combined emissions in g/km 221
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 275/40 ZR18 (103Y) XL
Tyre dimensions rear 285/35 ZR19 (103Y) XL
Wheel dimensions and material front 9.5Jx18 inches, light-alloy
Wheel dimensions and material rear 10.5Jx19 inches, light-alloy

Weight

Unladen weight EU in kg 1,780
Max. permissible weight in kg 2,210
Permitted load in kg 505
Permitted axle load front/rear in kg 1,080/1,180
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg -
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg -

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 353 (480)/6,250
Engine torque (Nm) at 1/min 550/2,650-6,130
Compression ratio : 1 9.3

Performance

Top speed in km/h 250 (290)
Acceleration 0–100 km/h in s 4.2

Fuel consumption

Urban in l/100 km 13.7
Extra-urban in l/100 km 8.0
Combined in l/100 km 10.1
CO2 combined emissions in g/km 230
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 275/40 ZR18 (103Y) XL
Tyre dimensions rear 285/35 ZR19 (103Y) XL
Wheel dimensions and material front 9.5Jx18 inches, light-alloy
Wheel dimensions and material rear 10.5Jx19 inches, light-alloy

Weight

Unladen weight EU in kg 1,745
Max. permissible weight in kg 2,245
Permitted load in kg 575
Permitted axle load front/rear in kg 1,115/1,230
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg 1,800

Engine

Cylinders/valves 6/4
Capacity in ccm 2,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 285 (387)/5,800-6,500
Engine torque (Nm) at 1/min 500/1,800-5,000
Compression ratio : 1 10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.4

Fuel consumption

Urban in l/100 km 10.0
Extra-urban in l/100 km 6.4
Combined in l/100 km 7.7
CO2 combined emissions in g/km 177
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/45 R18 95 Y XL
Tyre dimensions rear 255/40 R18 99 Y XL
Wheel dimensions and material front 7.5 J x 18 inches, light-alloy
Wheel dimensions and material rear 8.5 J x 18 inches, light-alloy

Weight

Unladen weight EU in kg 1,855
Max. permissible weight in kg 2,260
Permitted load in kg 480
Permitted axle load front/rear in kg 1,125/1,200
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg -
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg -

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 375 (510)/6,250
Engine torque (Nm) at 1/min 650/2,750-5,500
Compression ratio : 1 9.3

Performance

Top speed in km/h 250 (290)
Acceleration 0–100 km/h in s 3.5

Fuel consumption

Urban in l/100 km 14.1
Extra-urban in l/100 km 7.9
Combined in l/100 km 10.2
CO2 combined emissions in g/km 232
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 275/35 ZR19 (100Y) XL
Tyre dimensions rear 285/30 ZR20 (99Y) XL
Wheel dimensions and material front 9.5Jx19 inches, light-alloy
Wheel dimensions and material rear 10.5Jx20 inches, light-alloy

Fuel consumption and CO2 emissions of the BMW 3 Series Sedan M Automobiles.

BMW M3 Competition Sedan:
Fuel consumption in l/100 km (combined): x.x–x.x
CO2 emissions in g/km (combined): xxx–xxx


BMW M3 Sedan:
Fuel consumption in l/100 km (combined): x.x–x.x
CO2 emissions in g/km (combined): xxx–xxx


BMW M340i xDrive Sedan:
Fuel consumption in l/100 km (combined): 7.3–7.0
CO2 emissions in g/km (combined): 167–159


BMW M340d xDrive Sedan:
Fuel consumption in l/100 km (combined): 5.7–5.3
CO2 emissions in g/km (combined): 149–139


The information on fuel consumption, CO2 emissions and energy consumption has been determined in accordance with the prescribed measurement procedure VO (EU) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.



Further information about the official fuel consumption and the official specific CO2 emissions for new passenger automobiles can be found in the 'New Passenger Vehicle Fuel Consumption and CO2 Emission Guidelines', which are available free of charge at all sales outlets and from DAT Deutsche Automobil Treuhand GmbH, Hellmuth-Hirth-Str. 1, 73760 Ostfildern, Germany and on https://www.dat.de/co2



The values are already based on the new WLTP regulation and are translated back into NEDC-equivalent values in order to ensure the comparison between the vehicles. For vehicle related taxes or other duties based (at least inter alia) on CO2-emissions the CO2 values may differ to the values stated here.

Citeşte în continuare
​

Fuel consumption and CO2 emissions of the BMW 3 Series Sedan M Automobiles.

  • BMW M3 Competition Sedan with M xDrive:
    Fuel consumption in l/100 km (combined): 10.2
    CO2 emissions in g/km (combined): 232

    BMW M3 Competition Sedan:
    Fuel consumption in l/100 km (combined): 9.6
    CO2 emissions in g/km (combined): 221

    BMW M3 Sedan:
    Fuel consumption in l/100 km (combined): 10.1
    CO2 emissions in g/km (combined): 230

    BMW M340i xDrive Sedan:
    Fuel consumption in l/100 km (combined): 7.7
    CO2 emissions in g/km (combined): 177

    The BMW Individual paint finish Skyscraper Gey metallic and the BMW Individual extended leather and full leather trims shown here will probably be available from 03/2021. The paint finish BMW Individual Aventurine Red III metallic is expected to be available from 07/2021.

    The values of fuel consumptions, CO2 emissions and energy consumptions shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

    The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the European Regulation in its current version applicable. The values shown are based on the fuel consumption, CO2 values and energy consumptions according to the NEDC cycle for the classification.

    For further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the „handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars“, which is available at all selling points and at https://www.dat.de/angebote/verlagsprodukte/leitfaden-kraftstoffverbrauch.html.
